BC Slim Patchcord Cat6A FTP LSOH 1m Grey

Application
Bergen Cabling Cat6a FTP slim patchcords are designed for high density environments such as data centers and telecommunication rooms. The outer diameter is 40% reduced compared to traditional patchcords thus saving space in e.g. a rack.

Features
TIA/EIA-568B.2-1;ISO/IEO 11801;NEC/CEC
CMP, CMR, CM, UL listed
Application: Horizontal communication cable; for indoor installation

Wiring Scheme
ANSI/TIA/EIA-568-C.2: T568B
ISO/IEC 11801: 8-position conductor/pair assignment (1-2/3-6/4-5/7-8)

Transmission Performance
NSI/TIA-568-C.2: category 6A (1-500 MHz) specifications

Cordage
Construction: 4 pairs, 7 strands, 32 AWG, FTP
Cable Type: FTP Cat.6A Patch Cable
Outer Cable Diameter: 3.8mm ± 0.15mm
Pair Identification: Pair1= Blue/White Pair2= Orange/White
Pair 3= Green/White Pair4= Brown/White
Outer Jacket: LSZH Jacket
Plug
Type: Shielded RJ45 8P8C gold plated two pieces short body plug
